DIS Sensor
>>
Sensor/Switch ควบคุมการสั่นสะเทือน
[4]
>>
2
.jpeg)
Acceleration sensors (QG65 series) เซ็นเซอร์วัดความลาดเอียงแบบ 1, 2 แกน MEMS Technology มีความทนทานสูง
(1).jpeg)
TYPES OF INCLINATION SENSORS
DIS inclination sensors are available with the following general specifications:
| Single axis measurement range: | ±10°; ±30°; ±90°; 0 - 360° |
| Double axis measurement range: | ±10°; ±30°; ±90° |
| Analogue output: | 0.5 - 4.5 V or 4 - 20 mA |
| Digital output: | CANopen (Safety); RS232 |
| Level of protection: | IP67 (optional IP68 of IP69K) |
| Programmable: | filtering, measuring range |
| Zeroing possibilty: | depends on model |
| Functional safety: | SIL2/PLd (optional) |
| Housing: |
(reinforced) plastic or stainless steel |
