Power supply standard: AC: 24, 230 V ± 10%, 50 Hz; DC: 12-36 V ± 10%; on request: AC: 48, 60, 110, 120, 220, 240, 400 V ± 10%, 50/60 Hz; DC: 6-12, 36-80, 110, 220 V ± 10%

Storage temperature AC: -40°C ÷ +70°C; DC: -20°C ÷ +70°C

Operating temperature AC: -25°C ÷ +70°C; DC: -10°C ÷ +55°C

Power consumption AC: max. 8 mA; DC: max. 9 mA

Protection class : IP 65 front, IP 00 terminals

Display AC: 5 integers, 2 decimals; DC: 6 integers, 1 decimal; AC indicator; digit height: 4 mm

Displayed values range AC: 99999,99 h; DC: 999999,9 h

Mounting : panel

Reset : without reset

Accuracy AC: 1/100 h (36 sek.); DC: 1/10 h (6 min)

Case dimensions : 36 x 24 x 51 mm

Panel cut-out dimensions : 33 x 22 mm
