Current consumption AC: max. 8 mA; DC: max. 9 mA

Storage temperature AC: -40°C ÷ +70°C; DC: -20°C ÷ +70°C

Operating temperature AC: -25°C ÷ +70°C; DC: -10°C ÷ +55°C

Power supply standard: AC: 230 V ± 10%, 50 Hz; on request: AC: 24, 48, 60, 110, 120, 220, 240, 400 V ± 10%, 50/60 Hz; DC: 6-12, 36-80, 110, 220 V ± 10%

Protection class IP 65 front, terminals IP 00

Display AC: 5 integers, 2 decimals; DC: 6 integers, 1 decimal; AC indicator; digit height: 4 mm

Displayed values range AC: 99999,99 h; DC: 999999,9 h

Reset without reset

Mounting DIN rail TS-35 mounting

Accuracy AC: 1/100 h (36 s); DC: 1/10 h (6 min)

Case dimensions 35 x 85 x 55 mm
