Output voltage adjustable range

1.0 - 20 V

Output current adjustable range

0 - 5 A

Load from 10 % to 100 % variation

70 mV

Line from 180 to 264 V AC variation

20 mV

Ripple & noise in r.m.s.

5 mV

Ripple & noise (peak to peak)

30 mV

Load from 10 % to 100 % variation

20 mA

Line from 180 to 264 V AC variation

20 mA

Ripple & noise (peak to peak)

20 mA

Switching operation frequency

80 - 120 kHz

Power factor

0,68

Efficiency at maximum power

84 %

Voltmeter accuracy

± 1,0 % + 3 dgt.

Ampermeter accuracy

± 1,0 % + 3 dgt.

LCD-display

CC, CV, A, V, output ON-OFF

Operation voltage

200 ~ 240 V AC; 50/60 Hz

Dimensions (WxHxD)

70 x 150 x 250 mm

Weight

2 kg

EAN-13

4250569401497
