Technical Data

Rate supply voltage Us:   AC/DC 24-240V, < 3 W, < 7 VA

2 Measuring inputs:   Pt100, Pt1000, Thermocouples types B, E, J, K, L, N, R, S, 0/4-20mA(22ohm), 0-10V(13ohm)

Measuring time:   <2.5 s to 5 s.

Analog output:   0/4-20mA, max 500 ohm, 0-10V max. 10mA

Relay output:   2 x 1 change-over contacts

Rated ambient Temperature:   -20…+65 degC

Dimensions (H x W x D):   90 x 70 x 58 mm

Protection Housing/Terminals:   IP 30/IP 20

Weight:   200 g

More detail please read from data sheet….
