Technical Data

                Rated Supply Voltage:   AC/DC 24-240 V, 0/45…65 Hz

                Rated Supply Voltage:   DC 20.4…297V / AC 20.4…264V

                Power Consumption:   <0.5w, <1.2 VA

                Relay-output:   2 Change-over contact (CO)

                Measuring Inputs:   1-8 current transformers

                Function:   Monitoring interval adjustable 1-8 days

                Test Conditions:   see general technical hints

                Rated ambient temperature Range:   -20…+65degC

                Dimensions (w x h x d):   70 x 90 x 58 mm

                Protection:   IP30/IP20

                Weight:   approx. 180g
