Technical Data

 Rated supply voltage Us:   AC/DC 24-270V, 0/45...100 Hz, <5 VA, DC 20.4…297V, AC 20.4…297V

Relay output:   2 change-over contacts

Measuring voltage DC:   10…600V

Measuring voltage phase/phase:   AC 26…830V

Measuring voltage phase/neutral:   AC 15…480V

Frequency:   40…100 Hz

Measuring time DC:   DC average over 50 ms

Measuring time AC:   <50ms

Hysteresis:   adjustable AC 1…99V

Range Asymmetry:   5…50%

Switching delay:   0.05…9.99 s

Dimensions (H x W x D):   90 x 70 x 58 mm

Protection Housing/Terminals:   IP 30/IP 20

Weight:   app. 200 g
