Technical Data

Supply voltage:   DC 9 – 30V (2-wire), depending on load

Monitoring range:   AC 0 – 20/0 - 100A

Analog output:   DC 4 – 20mA (max. 32mA)

Adjustment time:   <0.5 s.

Nominal frequency:   50Hz

Operating range:   30 – 400 Hz

Overload cap:   63A / 360A

Rated ambient temperature:   0 – 55 DegC

Dimensions (h x w x d):   42 x 36 x 56 mm

Weight:   app. 90 g
