Technical Data

Supply voltage Us:   AC/DC 24 - 240V, 0/50/60 Hz, < 2 W, < 3 VA

Relay output:   1 change-over contacts (co)

Measuring signals:   DC 0/4…20 mA, 20 ohm, 0…10V, 63 kohm

Switching point:   adjustable 0…100%

Hysteresis:   adjustable 5…30% of set limit

Switching delay:   adjustable 0.1 – 10 sec.

Rated ambient Temperature:   -20…+55 degC

Dimensions (H x W x D):   90 x 35 x 58 mm

Protection Housing/Terminals:   IP 30/IP 20

Weight:   130 g
