Power supply : 3.6V 1/2AA Lithium Battery (inside), 7 years (replaceable)



Measurement range : 0.0 - 999999.9



Display : 7 digits, 7-segment LCD, 8 mm



Inputs : 1 x pulse input: Dry Contact/OC/Voltage (NPN Transistor) or Wide-Range Voltage



Input : levels Dry Contact/OC/Voltage: L < 0.8V, H: 2 - 30 V; Wide-Range Voltage: L: 0 - 10V AC/DC, H: 20 - 250V AC/DC



Resolution : 1 count per 1/10 hour



Storage temperature : -20°C ÷ +65°C



Reset remote reset : dry contact/OC/voltage or wide-range voltage



Operating temperature : -10°C ÷ +55°C



Case dimensions : 48 x 24 x 42,4 mm



Case : panel



Protection class : IP 54 (panel surface)



Panel cut-out dimensions : 45 x 22,2 mm
