Technical Data

Rated supply voltage Us:   AC 230/400V, +10%/-15%, 3VA, 50 Hz

Admissible tolerance US:   +/-20%

Relay:   1 change-over contacts (co)

Rated ambient Temp. Range:   -20…+55 degC

Monitoring asymmetry:   Switching point adjustable 5…15%

Hysteresis (cos fi):   2%

Switching delay:   adjustable 0.1…12 s

Under/Overvoltage:   measuring voltage 3 AC 400V

Dimensions (H x W x D) mm:   75 x 22.5 x 110 mm

Protection Housing/Terminals:   IP 40/IP 20

Weight:   app. 160 g
