Technical Data

Rated supply voltage Us:   3-phase 380-415V, without neutral

Admissible tolerance US:   +10%/-15%

Frequency:   50/60 Hz

Relay output:   2 change-over contacts

Rated ambient Temp. Range:   -20…+55 degC

Monitoring asymmetry:   Switching point adjustable 5…25%

Hysteresis (cos fi):   2%

Switching delay:   0.5 s

Dimensions (H x W x D) mm:   75 x 22.5 x 115 mm

Protection Housing/Terminals:   IP 30/IP 20

Weight:   app. 150 g
