Housing&Mounting : 76mm x 34.5mm x 71mm plastic housing for panel, Mounting. Panel cut-out is 71x29mm.

Protection Class : NEMA 4X (Ip65 at front, Ip20 at rear).

Weight : Approximately 0.20 Kg.

Environmental Ratings : Standard, indoor at an altitude of less than 2000 meters with none condensing humidity.

Storage / Operating Temperature : -40 C to +80 C / -30 C to +80 C

Storage / Operating Humidity : 90 % max. (None condensing)

Installation : Fixed installation

Overvoltage Category : II.

Pollution Degree : II, office or workplace, none conductive pollution

Operating Conditions : Continuous

Supply Voltage and Power :: 115

Time Accuracy : within

Digital Input : Mechanical contact

Control Form : ON / OFF

Relay Output : 16(8) A@250 V V for Resistive load (Output Relay)

(Electrical life : 100.000 switching at full load)

Display : 14 mm Red 4 digits LED Display

LED : S (Green), P (Green), h (Red), m(Red),s (Red), Output (Red)

Internal Buzzer : ³83dB

Approvals : GOST-R,
