Technical Data

Rated supply voltage Us:   AC 230/400V, +10%/-15%, 3VA, 50 Hz

Power factor (cos fi):   -0.99 … +0.99

Hysteresis (cos fi):   0.05…0.20

Nominal current of motor:   0.2…10A (higher currents with current-transformers)

Overload capacity:   10A continuously, 15A max. 3 s

Input voltage:   AC 100…400 V, 48…62 Hz

Relay:   2 change-over contacts (co)

Rated ambient Temp. Range:   -20…+50 degC

Dimensions (H x W x D) mm:   90 x 70 x 58 mm

Protection Housing/Terminals:   IP 30/IP 20

Weight:   app. 300g
