38
>>
LINE/NOISE FILTER
>>
Data line filters
[3]
>>
3
Data line filters รุ่น USB 3.0 converter set 7896
Technical specifications
| performance | |||
|---|---|---|---|
| Local unit | Upstream port | usb3.0 Type B Male | |
| Downstream port | USB3.0 SFS*1 | ||
| remote unit | Upstream port | USB3.0 SFS*1 | |
| Downstream port | 4-port | ||
| Operation mode | Support USB3.0 5GBps, backwars compatability with usb 2.0/1.1 | 4-port | |
| connections | |||
| USB 3.0 input (local unit) | USB3.0 Type-B Female | ||
| USB 3.0 input (local unit) | >USB3.0 Type-B Female | ||
| Optical | >1x USB3.0 SFS+ port | ||
| Cable | |||
| Fiber cable type | >Multi-mode fiber:OM3-300*2 | ||
| Max. length | ><300m | ||
| Mechanical | |||
| Construction | >High-impact alufer enclosure | ||
| Dimensions (LxWxH) (Unit:mm) | Local extender | 104x114x28 | |
| Remote extender | 104x114x28 | ||
| Net weight | Local extender | 200g | |
| Remote extender | 350g | ||
| Environmental | |||
| Operating temperature | >High-impact alufer enclosure | ||
| Storage temperature | Local extender | 104x114x28 | |
| Operating humidity | Remote extender | 104x114x28 | |
| Storage humidity | Local extender | 200g | |
| power Requirements | |||
| External AC power adapter |
>Local unit: Power adapter at host is not required |
||
|
>Remote unit Input: 100-240VAC/50-60Hz 0.2A Output: 5VDC, 2.0A 5/2.5mm jack |
|||
| Power consumption |
Local unit: 2 Watts |
Remote unit: 3.5 watts | |
