Features

- The transmission of optical signals can be done through a single fiber since this allows for twice as much data transmission compared with a twin fiber type.

- Auto negotiation function allows UTP port to auto select 10M or 100M and Full Duplex or Half Duplex.

- UTP port supports MDI / MDI-X auto crossover

- Supporting flow control

- Supporting 1552 Byte packet

- Built-in protection against lightning can prevent great damage to the converter caused by the induction of a lightning stroke.

- Design of internal or external power supply for selection by users

Specifications

- Operating standards: IEEE802.3u, 10/100Base-TX and 100Base-FX

- MAC address table: 1K

- LED: Power, FX 100, FX Link/Act, TX 100, TX FDX, TX Link/Act.

- Power: AC 110V - 220V to DC 5V; DC48V to DC 5V

- Ambient temperature: 0 - 50 °C

- Storage temperature: -20 - +70 °C

- Humidity: 5% - 90%

Connector

- UTP: RJ-45 10/100Mbps

- Fiber: SC 100Mbps

Cable

- UTP: Cat. 5 UTP (max. distance up to 100m)

- Fiber (single mode): 8.3/125, 8.7/125, 9/125, 10/125μm (max. distance up to 90km)

Flow control

- Full Duplex: IEEE802.3x

- Half Duplex: Backpressure

Dimensions

- Internal power: 30×110×140mm

- External power: 26×70×93mm
